Pr0-GRADE#68-12 Dual Band Repeater System
Premium 68dB High Power 12 Watts System
Commercial grade high output repeater system available for consumer use! This linear high quality repeater is comparable to carrier grade repeaters and is used in many commercial and government applications across Canada (see high profile customer list on home page).
Very high gain (dB) and Very high output power (dBm). Has a total of 12 Watts total output power for the uplink (to the local towers) and 12 Watts total for the downlink (for coverage in the building) with a very high 68dB gain for both the 850Mhz and 1900Mhz bands. Will cover any Rogers Wireless cell signals, any Bell Mobility cell signals, and any regular Telus cell signals in Canada. (Not for Telus Mike or Wind Mobile)
Complete with multi-level attenuator adjustment switches for the uplink/downlink on both bands (the only way to do a maximum perfect repeater system set up) (requires our professional phone support for proper adjustment on start up which is provided by us at no extra cost with the purchase of this kit) and amp block overdrive warning lights so you can maximize the uplink/downlink signals for both bands with this repeater kit to get the high gain/output power/signal compression power for LARGE indoor coverage areas with the maximum downlink as possible without overdriving the amp blocks, and reduce the uplink if you are using this repeater for commercial buildings in urban areas to prevent a “noise” attack on the carrier’s local towers if you are very close to them.
Recommended for multiple indoor antenna installations with up to 4 indoor antennas for large buildings. Can also be extended for very large buildings by adding additional Bi-Directional Amplifiers on the ends of very long shielded cable runs for even more coverage if necessary (see pictures for Stratford Hospital Installation). For 1 or 2 indoor antennas in large open areas, this repeater system will cover huge indoor warehouse or office areas. Can also be used for residential in urban or rural areas for VERY POWERFUL indoor coverage.
Also recommended for use in urban areas if your subject building is very close to any local cell towers to avoid carrier interference as we have full control over all bands uplink/downlink levels to help you solve ANY indoor cell signal coverage issue!
Custom shielded cable lengths are available for this kit as well as 2 to 4 way splitters with oscillation protection, lightning protectors and multiple indoor antennas for whatever your building cell coverage requires.
